Product EN0055-2

Description
Brake disc
Axe
Front
No. of Pieces
2
Url
https://catalogonuevo.energitbrakes.com/Producto/Details?idProducto=EN0055-2
Weight (gr.)
19588
R90 Homologation
R90 90R-02C0433/0076
Measures
Ø304x28x48
Brake Disc Type: Vented
Minimum thickness [mm]: 26
Hole Arrangement/Number: 5
Bolt Hole Circle Ø [mm]: 108
Wheel Hub Diameter [mm]: 71
Brand OE Reference
FIAT 9 467 548 587
FIAT 9 467 548 588
PEUGEOT 16 188 651 80
PEUGEOT 4249.24
PEUGEOT 4249.25
PEUGEOT 4249.92
Maker Cross reference
ATE 24.0128-0216.1
ATE 428216
BOSCH 0 986 479 380
BREMBO 09.A430.10
BREMBO 09.A430.1X
BREMBO 09.A430.75
DELPHI LOCKHEED BG4083
FERODO DDF1615
LETEC LBC022V
SANLI SL33839
TEXTAR 92157000
TEXTAR 92157003
TRW DF4849S
CITROËN
C5 (RC_) Hatchback 08/2004-
Vehicle Engine Fuel Date CC KW CV Traction
2.0 16V (RCRFJB, RCRFJC)

RFJ (EW10A)

 1 09/2004-08/2008 1997 103 140 1
C5 II (RD_) Saloon 02/2008-
Vehicle Engine Fuel Date CC KW CV Traction
1.6 (RD5FMA)

5FM (EP6DT)

 1 03/2011-06/2014 1598 120 163 1
1.6 THP 150 (RD5FN8, RD5FNA)

5FN (EP6CDT)

 1 07/2010-07/2016 1598 110 150 1
1.6 THP 155 (RD5FV8, RD5FNA)

5FV (EP6CDT)

 1 04/2009-07/2016 1598 115 156 1
1.6 VTi 120 (RD5FS8, RD5FSA)

5FS (EP6C)

 1 07/2010-06/2015 1598 88 120 1
1.8 16V (RD6FXC)

6FY (EW7A)

 1 02/2008-10/2010 1749 92 125 1
2.0 16V (RDRFJC, RDRFJF)

RFJ (EW10A)

 1 02/2008-10/2014 1997 103 140 1
2.0 16V BioFlex (RDRFJF)

RFJ (EW10A)

 19 02/2008-12/2012 1997 103 140 1
1.6 HDi 110 (RD9HL0, RD9HR8, RD9HRA)

9HL (DV6C)

9HR (DV6C)

 2 07/2010-05/2012 1560 82 112 1
1.6 HDi 110 (RD9HZC)

9HZ (DV6TED4)

 2 02/2008-10/2010 1560 80 109 1
1.6 HDi 115 (RD9HRA, RD9HLA, RD9HL0)

9HL (DV6C)

9HR (DV6C)

 2 01/2012-06/2015 1560 84 114 1
2.0 HDi (RDRHD8, RDRHDJ, RDRHR8, RDRHRJ)

RHF (DW10BTED4)

RHR (DW10BTED4)

 2 02/2008-06/2014 1997 100 136 1
2.0 HDi (RDRHR8)

RHR (DW10BTED4)

 2 10/2014-05/2017 1997 101 138 1
2.0 HDi 140 (RDRHF8, RDRHFA, RDRHA8, RDRHAJ)

RHF (DW10BTED4)

 2 11/2008-06/2015 1997 103 140 1
2.0 HDi 150 / BlueHDi 150 (RWRHEJ, RWRHE8)

AHR (DW10FD)

RHE (DW10CTED4)

 2 04/2009-05/2017 1997 110 150 1
2.0 HDi 165 (RDRHHA, RDRHH8)

RHH (DW10CTED4)

 2 04/2009-07/2016 1997 120 163 1
C5 II (RW_) Estate 02/2008-
Vehicle Engine Fuel Date CC KW CV Traction
1.6 THP 150

5FN (EP6CDT)

 1 04/2009-07/2016 1598 110 150 1
1.6 THP 155

5FV (EP6CDT)

 1 04/2009-07/2016 1598 115 156 1
1.6 VTI 120

5FS (EP6C)

 1 07/2010-06/2015 1598 88 120 1
1.8 i 16V (RW6FYC)

6FY (EW7A)

 1 02/2008-10/2010 1749 92 125 1
2.0 i 16V (RWRFJC, RWRFJF)

RFJ (EW10A)

 1 02/2008-10/2014 1997 103 140 1
2.0 16V BioFlex

RFJ (EW10A)

 19 02/2008-06/2010 1997 103 140 1
1.6 HDi 110

9HL (DV6C)

9HR (DV6C)

 2 07/2010-05/2012 1560 82 112 1
1.6 HDi 110 (RW9HZC)

9HZ (DV6TED4)

 2 02/2008-10/2010 1560 80 109 1
1.6 HDi 115

9HL (DV6C)

9HR (DV6C)

 2 06/2012-06/2015 1560 84 114 1
2.0 HDi

RHR (DW10BTED4)

 2 02/2008-06/2014 1997 100 136 1
2.0 HDi 140

RHF (DW10BTED4)

 2 04/2009-06/2015 1997 103 140 1
2.0 HDi 150 / BlueHDi 150 (RWRHEJ, RWRHE8)

AHR (DW10FD)

RHE (DW10CTED4)

 2 04/2009-05/2017 1997 110 150 1
2.0 HDi 165

RHH (DW10CTED4)

 2 04/2009-07/2016 1997 120 163 1
JUMPY II / DISPATCH () Platform/Chassis 11/2006-
Vehicle Engine Fuel Date CC KW CV Traction
2.0 I (X_RFH) 1 11/2006-03/2016 1997 103 140 1
1.6 HDi 90 16V

9HU (DV6UTED4)

 2 06/2007-03/2016 1560 66 90 1
1.6 HDi 90 8V

9HH (DV6DUM)

 2 06/2007-03/2016 1560 66 90 1
2.0 HDI (X_RHG) 2 01/2009-03/2016 1997 88 120 1
2.0 HDI (X_RHH) 2 07/2010-03/2016 1997 120 163 1
2.0 HDI 100 (X_AHY) 2 07/2011-03/2016 1997 72 98 1
2.0 HDi 125

AHZ (DW10CD)

 2 07/2011- 1997 94 128 1
JUMPY II / DISPATCH (VF7) Bus 01/2007-
Vehicle Engine Fuel Date CC KW CV Traction
2.0 i

RFH (EW10A)

RFJ (EW10A)

 1 01/2007-03/2016 1997 103 140 1
1.6 HDi 90 16V

9HU (DV6UTED4)

 2 01/2007-03/2016 1560 66 90 1
1.6 HDi 90 8V

9HH (DV6DUM)

9HM (DV6UC)

 2 01/2007-03/2016 1560 66 90 1
2.0 HDi 120

RHK (DW10UTED4)

 2 01/2007-03/2016 1997 88 120 1
2.0 HDi 125

AHZ (DW10CD)

 2 07/2011-03/2016 1997 94 128 1
2.0 HDi 140

RHR (DW10BTED4)

 2 01/2007-03/2016 1997 100 136 1
2.0 HDi 165

RHH (DW10CTED4)

 2 07/2010-03/2016 1997 120 163 1
2.0 HDi 95

AHY (DW10CE)

 2 07/2011-03/2016 1997 72 98 1
JUMPY II / DISPATCH () Van 01/2007-
Vehicle Engine Fuel Date CC KW CV Traction
2.0 i

RFH (EW10A)

 1 01/2007-03/2016 1997 103 140 1
1.6 HDi 90 16V

9HU (DV6UTED4)

 2 01/2007-03/2016 1560 66 90 1
1.6 HDi 90 8V

9HH (DV6DUM)

9HM (DV6UC)

 2 01/2007-03/2016 1560 66 90 1
2.0 HDi 120

RHK (DW10UTED4)

 2 01/2007-03/2016 1997 88 120 1
2.0 HDi 120 4x4

RHK (DW10UTED4)

 2 01/2010-03/2016 1997 88 120 3
2.0 HDi 125

AHZ (DW10CD)

 2 07/2011-03/2016 1997 94 128 1
2.0 HDi 125 4x4

AHZ (DW10CD)

 2 07/2011-03/2016 1997 94 128 3
2.0 HDi 140

RHR (DW10BTED4)

 2 01/2007-03/2016 1997 100 136 1
2.0 HDi 165

RHH (DW10CTED4)

 2 07/2010-03/2016 1997 120 163 1
2.0 HDi 95

AHY (DW10CE)

 2 07/2011-03/2016 1997 72 98 1
FIAT
SCUDO II (270_, 272_) Van 01/2007-
Vehicle Engine Fuel Date CC KW CV Traction
1.6 D Multijet

9HU

 2 01/2007-03/2016 1560 66 90 1
2.0 D Multijet

RHK

 2 01/2007-03/2016 1997 88 120 1
2.0 D Multijet

RH02

 2 05/2011-03/2016 1997 94 128 1
2.0 D Multijet

RHR

 2 01/2007-03/2016 1997 100 136 1
2.0 D Multijet

RH02

RHH

 2 07/2010-03/2016 1997 120 163 1
2.0 D Multijet 4x4

RHK

 2 01/2007-03/2016 1997 88 120 3
2.0 D Multijet 4x4

RH02

 2 05/2011-03/2016 1997 94 128 3
2.0 D Multijet 4x4

RHR

 2 01/2007-03/2016 1997 100 136 3
SCUDO II (270_, 272_) Bus 01/2007-
Vehicle Engine Fuel Date CC KW CV Traction
1.6 D Multijet

9HU

 2 01/2007-03/2016 1560 66 90 1
2.0 D Multijet

RHK

 2 01/2007-03/2016 1997 88 120 1
2.0 D Multijet

RH02

 2 04/2011-03/2016 1997 94 128 1
2.0 D Multijet

RHR

 2 01/2007-03/2016 1997 100 136 1
2.0 D Multijet

RH02

RHH

 2 07/2010-03/2016 1997 120 163 1
2.0 D Multijet 4x4

RHK

 2 01/2007-03/2016 1997 88 120 3
2.0 D Multijet 4x4

RH02

 2 04/2011-03/2016 1997 94 128 3
2.0 D Multijet 4x4

RHR

 2 01/2007-03/2016 1997 100 136 3
SCUDO II (270_, 272_) Platform/Chassis 01/2007-
Vehicle Engine Fuel Date CC KW CV Traction
1.6 D Multijet

9HU

 2 01/2007-03/2016 1560 66 90 1
2.0 D Multijet

RHK

 2 01/2007-03/2016 1997 88 120 1
2.0 D Multijet

RH02

 2 05/2011-03/2016 1997 94 128 1
2.0 D Multijet

DW10BTED4

RHR

 2 01/2007-03/2016 1997 100 136 1
2.0 D Multijet

RH02

RHH

 2 07/2010-03/2016 1997 120 163 1
PEUGEOT
407 (6C_) Coupe 10/2005-
Vehicle Engine Fuel Date CC KW CV Traction
2.0 HDi

RHH (DW10CTED4)

 2 06/2009- 1997 120 163 1
EXPERT II (VF3A_, VF3U_, VF3X_) Van 01/2007-
Vehicle Engine Fuel Date CC KW CV Traction
2.0 16V

RFH (EW10A)

RFJ (EW10A)

 1 01/2007- 1997 103 140 1
1.6 HDi 90 16V

9HU (DV6UTED4)

 2 01/2007- 1560 66 90 1
1.6 HDi 90 8V

9HH (DV6DUM)

9HM (DV6UC)

 2 01/2007- 1560 66 90 1
2.0 HDi 100 2 03/2011- 1997 72 98 1
2.0 HDi 120

RHK (DW10UTED4)

 2 01/2007- 1997 88 120 1
2.0 HDi 120 4x4

RHK (DW10UTED4)

 2 01/2010- 1997 88 120 3
2.0 HDi 130

AHZ (DW10CD)

 2 03/2011- 1997 94 128 1
2.0 HDi 130 4x4

AHZ (DW10CD)

 2 01/2012-03/2016 1997 94 128 3
2.0 HDi 140

RHR (DW10BTED4)

 2 01/2007- 1997 100 136 1
2.0 HDi 165

RHH (DW10CTED4)

 2 09/2009- 1997 120 163 1
EXPERT II () Platform/Chassis 01/2007-
Vehicle Engine Fuel Date CC KW CV Traction
2.0 16V (X_RFH) 1 01/2007-03/2016 1997 103 140 1
1.6 HDi 90 16V

9HU (DV6UTED4)

 2 01/2007- 1560 66 90 1
1.6 HDi 90 8V

9HH (DV6DUM)

9HM (DV6UC)

 2 01/2007- 1560 66 90 1
2.0 HDi 120

RHK (DW10UTED4)

 2 01/2007- 1997 88 120 1
2.0 HDi 130

AHZ (DW10CD)

 2 03/2011- 1997 94 128 1
2.0 HDi 140

RHR (DW10BTED4)

 2 01/2007- 1997 100 136 1
2.0 HDi 165

RHH (DW10CTED4)

 2 09/2009- 1997 120 163 1
EXPERT II Tepee (VF3X_) Bus 01/2007-
Vehicle Engine Fuel Date CC KW CV Traction
2.0 16V

RFH (EW10A)

RFJ (EW10A)

 1 01/2007-03/2016 1997 103 140 1
1.6 HDi 90 16V

9HU (DV6UTED4)

 2 01/2007-03/2016 1560 66 90 1
1.6 HDi 90 8V

9HH (DV6DUM)

9HM (DV6UC)

 2 01/2007-03/2016 1560 66 90 1
2.0 HDi 100

AHY (DW10CE)

 2 03/2011-03/2016 1997 72 98 1
2.0 HDi 120

RHK (DW10UTED4)

 2 01/2007-03/2016 1997 88 120 1
2.0 HDi 120 4x4

RHK (DW10UTED4)

 2 01/2007-03/2016 1997 88 120 3
2.0 HDi 130

AHZ (DW10CD)

 2 03/2011- 1997 94 128 1
2.0 HDi 130 4x4

AHZ (DW10CD)

 2 03/2011-03/2016 1997 94 128 3
2.0 HDi 140

RHR (DW10BTED4)

 2 01/2007- 1997 100 136 1
2.0 HDi 165

RHH (DW10CTED4)

 2 09/2009- 1997 120 163 1
PARTNER (5_, G_) Platform/Chassis 03/1997-07/2008
Vehicle Engine Fuel Date CC KW CV Traction
1.6 HDi 75 2 02/2006-07/2008 1560 55 75 1
TOYOTA
PROACE (MDX_) Van 06/2013-03/2016
Vehicle Engine Fuel Date CC KW CV Traction
1.6 D (MDX9)

3WZ-TV

 2 06/2013-03/2016 1560 66 90 1
2.0 D (MDX3)

4WZ-FTW

 2 06/2013-03/2016 1997 94 128 1
2.0 D (MDX6)

4WZ-FHV

 2 06/2013-03/2016 1997 120 163 1
2.0 D 4x4 (MDX4)

4WZ-FTW

 2 06/2013-03/2016 1997 94 128 3
