Product EN0109-2


Description
Brake disc
Axe
Front
No. of Pieces
2
Url
https://catalogonuevo.energitbrakes.com/Producto/Details?idProducto=EN0109-2
Weight (gr.)
10212
R90 Homologation
R90 90R-02C0452/0119
Measures
Ø262x21x44.6
Brake Disc Type: Vented
Minimum thickness [mm]: 19
Hole Arrangement/Number: 4
Bolt Hole Circle Ø [mm]: 100
Wheel Hub Diameter [mm]: 64.2
Brand OE Reference
HONDA 45251-S5D-A10
HONDA 45251-S6D-E10
HONDA 45251-SK7-000
HONDA 45251-SK7-A00
HONDA 45251-SK7-A10
HONDA 45251-SK7-J00
HONDA 45251-SR0-A00
HONDA 45251-ST3-E10
LOTUS GBD90840
ROVER GBD840
ROVER SDB000990
ROVER SDB100600
Maker Cross reference
ATE 24.0121-0105.1
BOSCH 0 986 478 174
BREMBO 09.5509.10
BREMBO 09.5509.14
LETEC LBR012V
ROAD HOUSE 6224.10
SANLI SL33932
TRW DF3021
Vehicle Engine Fuel Date CC KW CV Traction
1.8 1 10/1990-09/1993 1850 77 105 1
Vehicle Engine Fuel Date CC KW CV Traction
1.8 LS 1 10/1993-09/2001 1797 125 170 1
Vehicle Engine Fuel Date CC KW CV Traction
1.8 GS-R 1 10/1993-09/2001 1797 147 200 1
1.8 LS 1 10/1993-09/2001 1797 125 170 1
Vehicle Engine Fuel Date CC KW CV Traction
1.5 1 09/2008- 1497 79 107 1
1.5 i-VTEC

L15A7

1 08/2009- 1497 85 114 1
1.5 i-VTEC (GM2)

L15A7

1 02/2009- 1497 88 120 1
1.5 CNG (GM2) 16 01/2011-11/2013 1497 75 102 1
iVtec CNG (GM2) 16 01/2011-11/2013 1497 75 102 1
1.5 Flex 19 08/2009-12/2014 1497 85 114 1
Vehicle Engine Fuel Date CC KW CV Traction
1.5 (GM6) 1 06/2015- 1496 97 132 1
1.5 4WD (GM9) 1 06/2015- 1496 97 132 3
1.5 i-VTEC (GM6) 1 09/2014- 1497 86 117 1
1.5 i-VTEC (GM6)

L15A7

L15Z1

1 01/2014- 1497 88 119 1
1.5 Hybrid (GM4) 13 12/2014- 1496 81 110 1
1.5 Hybrid (GM7) 13 09/2017- 1496 81 110 1
1.5 Hybrid 4WD (GM5) 13 12/2014- 1496 81 110 3
1.5 CNG (GM6) 16 01/2014-10/2019 1497 75 102 1
1.5 Flex

L15-A7

19 09/2014-10/2021 1497 85 116 1
1.5 i-DTEC

N15A1

2 01/2014- 1498 74 100 1
Vehicle Engine Fuel Date CC KW CV Traction
i-VTEC (GN2) 1 06/2020- 1498 89 121 1
1.0 Vtec Flexfuel (GN1)

P10A6

19 12/2019- 988 90 122 1
Vehicle Engine Fuel Date CC KW CV Traction
1.5 1.5 DOHC i-VTEC (GN5)

L15B1

1 04/2021- 1498 89 121 1
1.5 DOHC i-VTEC (GN5) 1 03/2021- 1498 89 121 1
1.0 Vtec Flexfuel

P10A6

19 11/2020- 988 90 122 1
Vehicle Engine Fuel Date CC KW CV Traction
1.6 i 16V Vtec (EE9)

B16A1

1 10/1989-09/1991 1595 110 150 1
Vehicle Engine Fuel Date CC KW CV Traction
1.6 VTi 16V (EG6)

B16A2

1 10/1991-11/1995 1595 118 160 1
Vehicle Engine Fuel Date CC KW CV Traction
1.5 (EG8)

D15B2

D15B7

D15Z1

1 10/1991-12/1995 1493 74 101 1
1.6 16V Vtec (EH9)

D16Z6

D16Z7

1 10/1991-11/1995 1590 92 125 1
1.6 4x4

D16Z7

1 01/1992-10/1995 1590 92 125 3
1.6 EX 1 08/1993-10/1995 1590 88 120 1
1.6 VTi (EG9)

B16A2

1 10/1991-11/1995 1595 118 160 1
Vehicle Engine Fuel Date CC KW CV Traction
1.5 1 08/1993-12/1995 1493 69 94 1
1.5 i LSi (EJ2)

D15B7

1 08/1993-11/1995 1493 74 101 1
1.6 i (EJ6) 1 01/1994-11/1995 1590 77 105 1
1.6 i Vtec 1 01/1994-11/1995 1595 118 160 1
1.6 i Vtec (EJ1)

D16Y6

D16Z9

1 01/1994-03/1996 1590 92 125 1
Vehicle Engine Fuel Date CC KW CV Traction
1.4 i (MA8, MB2)

D14A5

D14A7

D14Z3

1 09/1995-02/2001 1396 55 75 1
1.4 i (MA8, MB2)

D14A2

D14A6

D14A8

D14Z4

1 06/1995-02/2001 1396 66 90 1
1.5 16V (MB3)

D15Z8

1 01/1997-02/2001 1493 84 114 1
1.5 i Vtec-E (MA9)

D15Z3

1 09/1994-01/1997 1493 66 90 1
1.6 16V (MB4)

D16B2

1 01/1997-02/2001 1590 85 116 1
1.6 i (MB1)

D16Y3

1 09/1994-01/1997 1590 83 113 1
1.6 i Vtec (MB1)

D16Y2

1 09/1994-01/1997 1590 93 126 1
1.6 VTi (MB4)

B16A2

1 01/1997-02/2001 1595 118 160 1
2.0 i TD (MB7)

20T2R

2 01/1997-02/2001 1994 63 86 1
2.0 TDiC (MB7)

20T2N

2 11/1998-10/2000 1994 74 101 1
2.0 TDiC (MB7)

20T2N

2 11/1998-10/2000 1994 77 105 1
Vehicle Engine Fuel Date CC KW CV Traction
1.5 i (EK3)

D15Z4

D15Z6

1 11/1995-02/2001 1493 84 114 1
1.6 1 10/1995-12/2000 1590 93 126 1
1.6 1 10/1995-09/2000 1590 118 160 1
1.6 i Vtec (EK1, SO4)

D16Y6

D16Y8

1 11/1995-02/2001 1590 92 125 1
1.6 i Vtec 4x4

D16Z7

1 11/1995-02/2001 1590 92 125 3
1.6 VTi (EK4, SO4)

B16A2

1 11/1995-02/2001 1595 118 160 1
1.7 (EK9) 1 11/1997-03/2001 1668 92 125 1
Vehicle Engine Fuel Date CC KW CV Traction
1.5

D15Z3

1 11/1995-12/1996 1493 66 90 1
1.5 i (EK3)

D15Z6

1 11/1995-02/2001 1493 84 114 1
1.6

D16Y7

1 10/1995-12/2000 1590 79 107 1
1.6 1 10/1995-09/2000 1590 88 120 1
1.6 (MB1)

D16Y2

1 10/1995-03/2001 1590 93 126 1
1.6 i (EK1)

D16Y5

1 11/1995-02/2001 1590 84 114 1
1.6 VTEC Type R 1 08/1997-09/2000 1595 136 185 1
1.6 VTi (EK4)

B16A2

1 11/1995-02/2001 1595 118 160 1
1.4 LPG

D14Z4

18 01/1997-02/2001 1396 66 90 1
2.0 TDiC

20T2N

2 11/1998-10/2000 1994 77 105 1
Vehicle Engine Fuel Date CC KW CV Traction
1.6 (EJ6)

D16Y7

1 05/1996-04/1999 1590 79 107 1
1.6 i (EJ6)

D16Y7

1 03/1996-03/2000 1590 77 105 1
1.6 i Vtec (EM1)

D16Y8

1 03/1996-03/2000 1590 92 125 1
1.6 i Vtec (EM1)

B16A2

1 04/1999-12/2000 1595 118 160 1
Vehicle Engine Fuel Date CC KW CV Traction
1.4 16V (MB8)

D14A7

1 04/1998-02/2001 1396 55 75 1
1.4 16V (MB8)

D14A8

1 04/1998-02/2001 1396 66 90 1
1.5 16V (MB9)

D15Z8

1 04/1998-02/2001 1493 84 114 1
1.6 16V (MC1)

D16B2

1 04/1998-02/2001 1590 85 116 1
1.6 16V (MC1)

D16W4

1 04/1998-02/2001 1590 92 125 1
1.8 16V (MC2)

B18C4

1 04/1998-02/2001 1797 124 169 1
2.0 i D (MC3) 2 04/1998-02/2001 1994 74 101 1
2.0 i D (MC3)

20T2N

2 04/1998-02/2001 1994 77 105 1
Vehicle Engine Fuel Date CC KW CV Traction
1.4 i (EP1, EU7)

D14Z6

1 02/2001-09/2005 1396 55 75 1
1.4 iS (EP1, EU5, EU7)

D14Z5

D14Z6

1 11/2000-09/2005 1396 66 90 1
1.6 i (EP2, EU8, EU6)

D16V1

D16W7

1 02/2001-09/2005 1590 81 110 1
1.7 (ES1) 1 01/2000-08/2005 1668 92 125 1
Vehicle Engine Fuel Date CC KW CV Traction
1.4 (ES4)

D14Z5

1 12/2000-09/2005 1396 66 90 1
1.5 (ES8)

D15Y3

1 02/2003-09/2005 1493 82 112 1
1.6 (ES5)

D16W7

1 02/2001-09/2005 1590 81 110 1
1.7

D17A6

D17Z2

1 02/2001-09/2005 1668 85 116 1
1.7 LX, LXL 1 01/2001-04/2006 1668 85 116 1
1.8 1 07/2003-08/2005 1850 77 105 1
2.0 (ET1)

K20A3

1 10/2003-09/2005 1998 118 160 1
1.3 IMA (ED9, ES9)

LDA1

13 10/2003-09/2005 1339 61 83 1
Vehicle Engine Fuel Date CC KW CV Traction
1.6 i (EM1)

D16V1

1 02/2001-12/2005 1590 81 110 1
1.7 i (EM2)

D17A8

1 05/2001-12/2005 1668 88 120 1
1.7 i VTEC (EM2)

D17A5

D17A9

1 05/2001-12/2005 1668 92 125 1
Vehicle Engine Fuel Date CC KW CV Traction
1.6 i 16V Vtec (EE8)

B16A1

1 10/1989-02/1992 1595 110 150 1
Vehicle Engine Fuel Date CC KW CV Traction
1.5 (EG1)

D15B7

1 01/1994-04/1998 1493 77 105 1
1.6 ESi (EH6)

D16Y8

D16Z6

1 03/1992-12/1998 1590 92 125 1
1.6 i VTi (EG2)

B16A2

B16A3

1 03/1992-12/1998 1595 118 160 1
Vehicle Engine Fuel Date CC KW CV Traction
1.6 A las 4 ruedas (MB5)

D16A

D16Z2

1 10/1995-09/1999 1590 88 120 3
Vehicle Engine Fuel Date CC KW CV Traction
1.3 IMA (ZE2)

LDA3

13 04/2009- 1339 73 99 1
1.3 IMA (ZE28, ZE2)

LDA3

13 04/2009- 1339 65 88 1
1.5 IMA (ZE3) 13 10/2011- 1497 82 112 1
Vehicle Engine Fuel Date CC KW CV Traction
1.6 (DA5)

ZC

1 06/1989-07/1993 1590 88 120 1
Vehicle Engine Fuel Date CC KW CV Traction
1.5

D15B

1 09/1995-08/1999 1493 96 131 1
1.8 (DC2)

B18B2

1 07/1993-11/2001 1834 107 146 1
1.8 SiR (DC2)

B18C

1 09/1993-08/2001 1797 132 180 1
1.8 VTiR (DC2) 1 07/1993-11/1999 1797 125 170 1
1.8 VTiR (DC2)

B18C1

1 07/1993-11/1999 1797 127 173 1
Vehicle Engine Fuel Date CC KW CV Traction
1.4

L13Z1

1 11/2008- 1339 74 101 1
1.5 i-VTEC (GE8)

L15A7

1 07/2008-06/2014 1496 88 120 1
1.3 HYBRID (GP1)

LDA3

13 04/2011- 1339 75 102 1
1.5 Flex 19 11/2008-03/2014 1497 85 116 1
1.5 Flexfuel (GE8) 19 07/2008- 1496 88 120 1
Vehicle Engine Fuel Date CC KW CV Traction
1.5 (GG7)

L15A

1 03/2011-03/2014 1497 88 120 1
1.5 4WD (GG8)

L15A

1 03/2011-03/2014 1497 88 120 3
Vehicle Engine Fuel Date CC KW CV Traction
1.3

L13B

L13B2

1 09/2015- 1318 75 102 1
1.5

L15B3

1 09/2017- 1498 96 130 1
1.5 (GK5) 1 09/2014- 1496 97 132 1
1.5 4WD (GK6) 1 12/2013- 1496 97 132 3
1.5 i-VTEC Flex

L15Z2

19 09/2014- 1497 88 120 1
Vehicle Engine Fuel Date CC KW CV Traction
1.5 (GB1) 1 12/2001-10/2008 1497 66 90 1
1.5 (GB1) 1 12/2001-10/2008 1497 81 110 1
1.5 4WD (GB2) 1 12/2001-10/2008 1497 66 90 3
Vehicle Engine Fuel Date CC KW CV Traction
1.8

18 K4F

1 08/1995-11/2000 1796 88 120 2
111 S

18 K4K

1 03/1999-11/2000 1796 107 146 2
Vehicle Engine Fuel Date CC KW CV Traction
1.4

14 K4F

1 03/2003-05/2005 1396 76 103 1
1.8

18 K4F

1 03/2003-05/2005 1796 86 117 1
160

18 K4K

1 03/2003-05/2005 1796 118 160 1
2.0 TD

20 T2N

2 03/2003-05/2005 1994 74 101 1
2.0 TD

20 T2N

2 03/2003-05/2005 1994 83 113 1
Vehicle Engine Fuel Date CC KW CV Traction
105

14 K4F

1 06/2001-04/2005 1396 76 103 1
120

18 K4F

1 06/2001-04/2005 1796 86 117 1
2.0 TD

20 T2N

2 06/2001-04/2005 1994 74 100 1
2.0 TD

20 T2N

2 12/2002-04/2005 1994 83 113 1
Vehicle Engine Fuel Date CC KW CV Traction
1.6

16 K4F

1 07/2003-04/2005 1588 79 107 1
120

18 K4F

1 07/2001-04/2005 1796 86 117 1
180

25 K4F

1 07/2001-04/2005 2497 130 177 1
2.0 TD

20 T2N

2 01/2004-04/2005 1994 74 101 1
2.0 TD

20 T2N

2 01/2004-04/2005 1994 83 113 1
Vehicle Engine Fuel Date CC KW CV Traction
1.6

16 K4F

1 11/2001-10/2005 1590 82 111 1
120

18 K4F

1 07/2001-10/2005 1796 86 117 1
180

25 K4F

1 07/2001-10/2005 2497 130 177 1
2.0 TD

20 T2N

2 01/2004-10/2005 1994 74 101 1
2.0 TD

20 T2N

2 01/2004-10/2005 1994 83 113 1
Vehicle Engine Fuel Date CC KW CV Traction
1.1 1 11/1999-05/2005 1120 44 60 1
1.1

11 K4F

1 09/1999-06/2001 1120 55 75 1
1.1 16V

11 K4F

1 01/2004-05/2005 1120 55 75 1
1.4 16V

14 K4M

1 10/1999-05/2005 1396 62 84 1
1.4 16V

14 K4F

1 10/1999-05/2005 1396 76 103 1
1.6 16V

16 K4F

1 10/1999-05/2005 1588 80 109 1
1.8 16V

18 K4F

1 10/1999-05/2005 1796 85 116 1
1.8 16V

18 K4K

1 02/2000-05/2005 1796 107 146 1
2.0 iDT

20 T2N

2 10/1999-05/2005 1994 74 101 1
2.0 iDT

20 T2N

2 01/2002-12/2004 1994 83 113 1
Vehicle Engine Fuel Date CC KW CV Traction
1.4

14 K4M

1 01/2003-12/2005 1396 62 84 1
2.0 iDT

20 T2N

2 01/2003-12/2005 1994 74 101 1
Vehicle Engine Fuel Date CC KW CV Traction
1.4

14 K4F

1 02/2000-05/2005 1396 76 103 1
1.6

16 K4F

1 02/2000-05/2005 1588 80 109 1
1.8

18 K4F

1 02/2000-05/2005 1796 86 117 1
2.0 V6

20 K4F

1 02/2000-05/2005 1997 110 150 1
2.0 iDT

20 T2N

2 02/2000-05/2005 1994 74 101 1
2.0 iDT

20 T2N

2 01/2004-05/2005 1994 83 113 1
Vehicle Engine Fuel Date CC KW CV Traction
1.4

14 K4F

1 02/2000-05/2005 1396 76 103 1
1.6

16 K4F

1 02/2000-05/2005 1588 80 109 1
1.8

18 K4F

1 02/2000-05/2005 1796 86 117 1
2.0 V6

20 K4F

1 02/2000-05/2005 1997 110 150 1
2.0 iDT

20 T2N

2 02/2000-05/2005 1994 74 101 1
2.0 iDT

20 T2N

2 01/2004-05/2005 1994 83 113 1
Vehicle Engine Fuel Date CC KW CV Traction
214 GSi/Si

14 K4F

1 12/1992-10/1995 1396 76 103 1
216 GSi

D 16 Z2

1 01/1990-12/1995 1590 82 112 1
Vehicle Engine Fuel Date CC KW CV Traction
216 1.6

D 16 Z2

1 04/1990-02/1996 1590 82 111 1
216 1.6i 16V

16 K4F

1 01/1996-11/1999 1588 82 111 1
Vehicle Engine Fuel Date CC KW CV Traction
216

16 K4F

1 01/1996-12/1997 1588 82 112 1
220 GSi

20 T4H

1 05/1994-06/1999 1994 100 136 1
220TURBO

20 T4G

1 10/1992-06/1999 1994 147 200 1
Vehicle Engine Fuel Date CC KW CV Traction
1.4

14 K4D

1 01/1996-12/1997 1396 66 90 1
214 i

14 K2F

1 11/1995-03/2000 1396 55 75 1
214 Si

14 K4F

1 11/1995-03/2000 1396 76 103 1
216 Si

16 K4F

1 11/1995-06/1999 1588 82 112 1
218 K Vi

18 K4K

1 11/1995-03/2000 1796 107 146 1
218 Si

18 K4F

1 08/1999-03/2000 1796 88 120 1
220 D/SD

20 T2R

2 11/1995-03/2000 1994 63 86 1
Vehicle Engine Fuel Date CC KW CV Traction
416 GSI

D 16 Z2

1 04/1990-04/1995 1590 82 112 1
420 GSI/SLI/GTI/Vite

20 T4H

1 01/1993-04/1995 1994 100 136 1
420 GTI/GSI/Vitesse

20 M4F

1 02/1992-04/1995 1994 103 140 1
Vehicle Engine Fuel Date CC KW CV Traction
1.8 i

18 K4K

1 06/1996-11/1998 1796 107 146 1
2.0 i

20 T4H

1 05/1994-11/1998 1994 100 136 1
1.8 TD

XUD 7TE

2 09/1993-11/1998 1769 65 88 1
Vehicle Engine Fuel Date CC KW CV Traction
414

14 K2F

1 03/1996-12/1999 1396 55 75 1
414 Si

14 K4F

1 05/1995-03/2000 1396 76 103 1
416 Si

16 K4F

1 05/1995-03/2000 1588 82 112 1
416 Si

D 16 Y3

1 03/1995-06/1999 1590 83 113 1
416 Si

D16B2

1 05/1995-03/2000 1590 85 116 1
420 Si Lux

20 T4H

1 12/1995-03/2000 1994 100 136 1
420 D

20 T2R

2 11/1995-03/2000 1994 63 86 1
420 Di

20 T2N

2 05/1995-03/2000 1994 77 105 1
Vehicle Engine Fuel Date CC KW CV Traction
414

14 K2F

1 03/1996-12/1997 1396 55 75 1
414 Si

14 K4F

1 05/1995-03/2000 1396 76 103 1
416 Si

16 K4F

1 05/1995-03/2000 1588 82 112 1
416 Si

D16B2

1 06/1995-03/2000 1590 85 116 1
420 Si Lux

20 T4H

1 12/1995-03/2000 1994 100 136 1
420 D

20 T2R

2 11/1995-03/2000 1994 63 86 1
420 Di

20 T2N

2 05/1995-03/2000 1994 77 105 1
Vehicle Engine Fuel Date CC KW CV Traction
2.0 iDT

20 T2N

2 03/2003-04/2005 1994 74 101 1
Vehicle Engine Fuel Date CC KW CV Traction
1.6 16V

16 K4F

1 03/1996-11/1999 1588 82 111 1
1.8 16V

18 K4K

1 03/1996-11/1999 1795 107 145 1
Vehicle Engine Fuel Date CC KW CV Traction
1.4

14 K4M

1 08/2003-05/2005 1396 62 84 1
1.4

14 K4F

1 08/2003-05/2005 1396 76 103 1
1.6

16 K4F

1 01/2004-05/2005 1588 80 109 1
1.8

18 K4F

1 08/2003-05/2005 1796 86 117 1
2.0 TD

20 T2N

2 08/2003-05/2005 1994 74 101 1
Return
