Product EN0522-2
- Description
- Brake disc
- Axe
- Front
- No. of Pieces
- 2
- Url
- https://catalogonuevo.energitbrakes.com/Producto/Details?idProducto=EN0522-2
- Weight (gr.)
- 16390
- R90 Homologation
-
90R-02C0074/0090
- Measures
- Ø300x27.8x68.2
-
Brake Disc Type:
Vented -
Minimum thickness [mm]:
25.4 -
Hole Arrangement/Number:
5 -
Bolt Hole Circle Ø [mm]:
112 -
Wheel Hub Diameter [mm]:
80
| Brand | OE Reference |
|---|---|
| MERCEDES-BENZ | 126 421 04 12 |
| MERCEDES-BENZ | 126 421 05 12 |
| Maker | Cross reference |
|---|---|
| ATE | 24.0128-0102.1 |
| BENDIX ANTIGUO | 561453B |
| BENDIX BRAKING-TMD | BDS1911 |
| BOSCH | 0 986 478 197 |
| BREMBO | 09.4928.10 |
| DELPHI LOCKHEED | BG2372 |
| FERODO | DDF185 |
| GIRLING | 6015861 |
| HELLA-PAGID | 52116 |
| MINTEX | MDC450 |
| NECTO | WN418 |
| ROAD HOUSE | 6345.10 |
| TEXTAR | 92032500 |
| TRW | DF1586 |
| VALEO | 186459 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 260 SE (126.020) |
M 103.941 |
1 | 09/1985-06/1991 | 2599 | 118 | 160 | 2 |
| 260 SE (126.020) |
M 103.941 |
1 | 09/1985-06/1991 | 2599 | 122 | 166 | 2 |
| 300 SE, SEL (126.024, 126.025) |
M 103.981 |
1 | 01/1986-06/1991 | 2960 | 132 | 180 | 2 |
| 300 SE, SEL (126.024, 126.025) |
M 103.981 |
1 | 09/1985-12/1989 | 2960 | 138 | 188 | 2 |
| 420 SE, SEL |
M 116.965 |
1 | 10/1985-06/1991 | 4196 | 165 | 224 | 2 |
| 420 SE, SEL |
M 116.965 |
1 | 10/1985-12/1987 | 4196 | 170 | 231 | 2 |
| 420 SE, SEL (126.034, 126.035) |
M 116.965 |
1 | 10/1985-06/1991 | 4196 | 150 | 204 | 2 |
| 420 SE, SEL (126.034) |
M 116.965 |
1 | 10/1985-12/1987 | 4196 | 160 | 218 | 2 |
| 500 SE, SEL |
M 117.965 |
1 | 09/1987-06/1991 | 4973 | 185 | 252 | 2 |
| 500 SE, SEL |
M 117.965 |
1 | 09/1987-06/1991 | 4973 | 195 | 265 | 2 |
| 500 SE, SEL (126.036) |
M 117.965 |
1 | 09/1985-06/1991 | 4973 | 164 | 223 | 2 |
| 500 SE, SEL (126.036) |
M 117.965 |
1 | 09/1985-06/1991 | 4973 | 180 | 245 | 2 |
| 500 SE, SEL Cat |
M 117.965 |
1 | 06/1989-06/1991 | 4973 | 185 | 252 | 2 |
| 560 SE, SEL |
M 117.968 |
1 | 08/1987-06/1991 | 5547 | 205 | 279 | 2 |
| 560 SE, SEL |
M 117.968 |
1 | 10/1985-06/1991 | 5547 | 220 | 300 | 2 |
| 560 SE, SEL (126.038, 126.039) |
M 117.968 |
1 | 10/1985-06/1991 | 5547 | 178 | 242 | 2 |
| 560 SE, SEL (126.038) |
M 117.968 |
1 | 10/1985-12/1987 | 5547 | 200 | 272 | 2 |
| 300 SDL (126.125) |
OM 603.961 |
2 | 09/1986-12/1987 | 2996 | 107 | 146 | 2 |
| 300 SDL (126.125) | 2 | 09/1985-12/1986 | 2996 | 110 | 150 | 2 | |
| 350 SD, SDL | 2 | 09/1989-06/1991 | 3449 | 110 | 150 | 2 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 420 SEC (126.046) |
M 116.965 |
1 | 10/1985-06/1991 | 4196 | 150 | 204 | 2 |
| 420 SEC (126.046) |
M 116.965 |
1 | 10/1985-12/1987 | 4196 | 160 | 218 | 2 |
| 420 SEC (126.046) |
M 116.965 |
1 | 10/1985-06/1991 | 4196 | 165 | 224 | 2 |
| 420 SEC (126.046) |
M 116.965 |
1 | 09/1986-06/1991 | 4196 | 170 | 231 | 2 |
| 500 SEC (126.044) |
M 117.965 |
1 | 10/1985-06/1991 | 4973 | 164 | 223 | 2 |
| 500 SEC (126.044) |
M 117.965 |
1 | 09/1985-06/1991 | 4973 | 180 | 245 | 2 |
| 500 SEC (126.044) |
M 117.965 |
1 | 08/1987-06/1991 | 4973 | 185 | 252 | 2 |
| 500 SEC (126.044) |
M 117.965 |
1 | 09/1985-06/1991 | 4973 | 195 | 265 | 2 |
| 500 SEC Cat |
M 117.965 |
1 | 06/1989-06/1991 | 4973 | 185 | 252 | 2 |
| 560 SEC (126.045) |
M 117.968 |
1 | 10/1985-06/1991 | 5547 | 178 | 242 | 2 |
| 560 SEC (126.045) |
M 117.968 |
1 | 10/1985-12/1987 | 5547 | 200 | 272 | 2 |
| 560 SEC (126.045) |
M 117.968 |
1 | 10/1985-06/1991 | 5547 | 205 | 279 | 2 |
| 560 SEC (126.045) |
M 117.968 |
1 | 10/1985-12/1989 | 5547 | 220 | 300 | 2 |
