Product EN0580-2

Description
Brake disc
Axe
Front
No. of Pieces
2
Url
https://catalogonuevo.energitbrakes.com/Producto/Details?idProducto=EN0580-2
Weight (gr.)
14890
R90 Homologation
R90 90R-02C0074/0857
Measures
Ø285x28x45.5
Brake Disc Type: Vented
Minimum thickness [mm]: 26
Hole Arrangement/Number: 5
Bolt Hole Circle Ø [mm]: 110
Wheel Hub Diameter [mm]: 84
Brand OE Reference
TOYOTA 43512-26120
Maker Cross reference
BENDIX ANTIGUO 562118B
BOSCH 0 986 479 427
DELPHI LOCKHEED BG3190
FERODO DDF1039
TRW DF4347
TOYOTA
HiAce IV / QUANTUM (_H1_) Bus 08/1987-12/2004
Vehicle Engine Fuel Date CC KW CV Traction
2.0 (RZH102, RZH112)

1RZ

 1 08/1989-04/1998 1998 74 101 2
2.0 (RZH124) 1 11/1996-10/2000 1998 81 110 2
2.4 (RZH103, RZH183)

2RZ-E

 1 08/1989-08/2003 2438 88 120 2
2.4 (RZH125) 1 08/1989-10/1996 2438 72 98 2
2.4 4WD (RZH103_, RZH109_, RZH113_, RZH115_, RZH103R,...

2RZ-E

 1 08/1989-07/1995 2438 88 120 3
2.4 D (LH100, LH110, LH104, LH114)

2L

 2 08/1989-12/2004 2446 57 78 2
2.4 D (LH102)

2L

 2 08/1989-08/1995 2446 55 75 2
2.4 D 4WD (LH51_, LH61_, LH66_, LH71_, LH51R, LH61R,...

2L

 2 08/1987-08/1995 2446 55 75 3
2.8 D (LH105, LH125)

3L

 2 08/1989-08/2000 2779 61 83 2
3.0 D (LH174) 2 08/1998-08/2004 2986 65 88 2
3.0 TD (KCH40W)

1KZ-TE

 2 08/1999-05/2002 2982 104 141 2
HiAce IV (_H1_) Van 08/1989-02/2005
Vehicle Engine Fuel Date CC KW CV Traction
2.0 (RZH102, RZH112)

1RZ

 1 02/1990-08/2004 1998 74 101 2
2.0 (RZH102, RZH112) 1 11/1996-10/2000 1998 81 110 2
2.4 (RZH10)

2RZ-E

 1 08/1989-08/1995 2438 88 120 2
2.4 (RZH103_, RZH103R) 1 08/1989-10/1996 2438 72 98 2
2.4 4WD (RCH103_, RCH113_, RCH103R, RCH113R)

2RZ-E

 1 08/1989-08/1995 2438 88 120 3
2.4 i (RZH103, RZH113)

2RZ-E

 1 08/1998-08/2004 2438 85 116 2
2.4 D (LH102, LH104, LH112)

2L

 2 09/1989-08/1995 2446 57 78 2
2.4 D (LH112)

2L

 2 08/1989-08/2004 2446 55 75 2
2.4 D 4WD

2L

 2 09/1989-08/1995 2446 57 78 3
2.4 D 4WD (LH108, LH118)

2L

 2 08/1989-07/1999 2446 55 75 3
2.8 D (LH105, LH103, LH113)

3L

 2 08/1989-08/2000 2779 61 83 2
3.0 D (LH162, LH172) 2 08/1998-08/2004 2986 65 88 2
