Product EN0632-2
- Description
- Brake disc
- Axe
- Front
- No. of Pieces
- 2
- Url
- https://catalogonuevo.energitbrakes.com/Producto/Details?idProducto=EN0632-2
- Weight (gr.)
- 15700
- R90 Homologation
-
90R-02C0433/0076
- Measures
- Ø302x28x39
-
Brake Disc Type:
Vented -
Minimum thickness [mm]:
26.5 -
Hole Arrangement/Number:
5 -
Bolt Hole Circle Ø [mm]:
114.3 -
Wheel Hub Diameter [mm]:
73.4
| Brand | OE Reference |
|---|---|
| CHRYSLER | 04683918AB |
| CHRYSLER | 04683918AD |
| Maker | Cross reference |
|---|---|
| ATE | 24.0128-0147.1 |
| ATE | 428147 |
| BENDIX ANTIGUO | 562292B |
| BENDIX BRAKING-TMD | BDS1886 |
| BOSCH | 0 986 479 117 |
| BREMBO | 09.9743.10 |
| BREMBO | 09.9743.11 |
| DELPHI LOCKHEED | BG3716 |
| FERODO | DDF1372 |
| GIRLING | 6043461 |
| HELLA-PAGID | 8DD 355 107-881 |
| LETEC | LBU010V |
| MINTEX | MDC1554 |
| NECTO | WN1341 |
| ROAD HOUSE | 6602.10 |
| SANLI | SL33118 |
| TEXTAR | 92108200 |
| TRW | DF4346 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 3.8 | 1 | 01/1999-12/1999 | 3778 | 131 | 178 | 3 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 3.8 | 1 | 10/2000-09/2006 | 3778 | 160 | 218 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 3.8 AWD (GSHC52) | 1 | 10/1997-03/2001 | 3778 | 131 | 178 | 3 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 2.4 |
EDZ |
1 | 02/2000-12/2008 | 2429 | 108 | 147 | 1 |
| 2.4 |
EDZ |
1 | 04/2003-12/2007 | 2429 | 111 | 151 | 1 |
| 3.3 |
EGA EGM |
1 | 02/2000-12/2008 | 3301 | 128 | 174 | 1 |
| 3.3 |
EGM |
1 | 10/2000-09/2002 | 3301 | 131 | 178 | 1 |
| 3.3 | 1 | 09/2000-12/2007 | 3301 | 134 | 182 | 1 | |
| 3.3 AWD |
EGA |
1 | 02/2000-12/2008 | 3301 | 128 | 174 | 3 |
| 3.8 |
EGH |
1 | 02/2000-12/2008 | 3778 | 160 | 218 | 1 |
| 3.8 AWD |
EGH |
1 | 02/2000-12/2008 | 3778 | 160 | 218 | 3 |
| 3.3 Flex-Fuel | 19 | 02/2000-12/2008 | 3301 | 128 | 174 | 1 | |
| 2.5 CRD |
EDK |
2 | 08/2005-12/2008 | 2499 | 88 | 120 | 1 |
| 2.5 CRD |
ENJ |
2 | 02/2000-12/2008 | 2499 | 105 | 141 | 1 |
| 2.8 CRD |
ENR |
2 | 06/2004-12/2008 | 2777 | 110 | 150 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 3.3 (SYM53, SYH53) | 1 | 10/2000-06/2007 | 3301 | 128 | 174 | 1 | |
| 3.8 (SYX53) | 1 | 10/2000-06/2007 | 3778 | 160 | 218 | 1 | |
| 3.8 AWD (SCH53) | 1 | 10/2000-06/2007 | 3778 | 160 | 218 | 3 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 2.4 |
EDZ |
1 | 02/2000-12/2007 | 2429 | 112 | 152 | 1 |
| 3.3 |
EGA |
1 | 02/2000-12/2007 | 3301 | 128 | 174 | 1 |
| 3.3 |
EGM |
1 | 04/2001-05/2007 | 3301 | 132 | 179 | 1 |
| 3.3 AWD |
EGA |
1 | 02/2000-12/2007 | 3301 | 128 | 174 | 3 |
| 3.8 |
EGH |
1 | 04/2001-05/2007 | 3778 | 154 | 209 | 1 |
| 3.8 |
EGH |
1 | 02/2000-12/2007 | 3778 | 160 | 218 | 1 |
| 3.8 AWD |
EGH |
1 | 04/2001-12/2007 | 3778 | 153 | 208 | 3 |
| 3.8 AWD | 1 | 04/2001-05/2007 | 3778 | 154 | 209 | 3 | |
| 3.8 AWD |
EGH |
1 | 02/2000-12/2007 | 3778 | 160 | 218 | 3 |
